15.6-inch (396-mm) TFT (LED blacklight) 16:9-format HD capacitive touchscreen
Infrastructure management
HP Partner Link, HP Embedded Web Server, HP Web Jetadmin, PrintOS
Memory
8 GB DDR4
Print quality color (best)
1200 x 1200 dpi
Roll external diameter
Up to 177 mm
Supported Primary Applications
Line drawings
Maps
Orthophotos
Posters
Paper handling output, optional
High-capacity stacker (up to 500-page capacity)
Linear scan speed
Color: up to 15.24 cm/sec
Grayscale: up to 25.4 cm/sec
Scan resolution, optical
1200 dpi
Media types
Bond and recycled papers, poster papers, polypropylene, Tyvek papers, matte film
Media weight, recommended
70 to 200 g/m²
Power consumption
0.27 kW (typical)
0.7 kW (max printing)
95 W (ready)
<16 W (sleep)
Power
Input voltage (auto ranging) 100-127/200-240 V (±10%), 50/60 Hz (±3 Hz), 7/3.5 A
Operating temperature range
5 to 40ºC
Operating humidity range
20 to 80% RH, depending on media type
Electromagnetic compatibility
Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia and New Zealand (RCM), Japan (VCCI), Korea (KC)
Energy star certified
Yes
Safety
IEC 60950-1+A1+A2 and IEC 62368-1 2nd ed. compliant
USA and Canada (CSA listed)
EU (LVD and EN 60950-1 and 62368-1 compliant)
Russia, Belarus, and Kazakhstan (EAC)
China (CCC)
Environmental certification
ENERGY STAR, EPEAT Registered, UL 2801 ECOLOGO, CE marking (including RoHS, WEEE, REACH). In compliance with WW RoHS materials restriction requirements in China, Korea, India, Vietnam, Turkey, Serbia, and Ukraine
